FANTIC CABALLERO 500 SCRAMBLER red 2025 - 2026

MM 460 DOHC engine - The Italian heart of MY25

Following the success of the MM300FI engine, Fantic presents a new Italian engineering masterpiece: the MM 460 DOHC engine, entirely designed, developed and assembled in Italy. This 460 cc unit marks a total evolution in performance, weight and technology, while maintaining the authentic character of the Caballero.

Main technical features Fantic Caballero 500 2025

DOHC timing with finger follower rocker arms

• Dual overhead camshaft technology ensures precise and efficient timing.
• Finger-follower type rocker arms allow quick response at high revs.
• Perfect balance between low-end torque and sporty high-revving delivery.

Power and torque

• Maximum power of 45 hp at 8,250 rpm.
• High torque from low revs for mixed urban, sporty or adventurous use.
• Optimized to meet the legal limit of the A2 license.

Electronic throttle (Ride-by-Wire)

• Allows extremely precise engine calibration.
• Possibility of selecting different engine maps to adapt to each type of driving.
• Technological basis for the integration of advanced electronic aids in the future.

Anti-rebound clutch

• Prevents rear wheel lock-up when downshifting.
• Reduces lever effort, improving control and safety in active driving.

Lightweight and compact design

• Weighs less than 40 kg thanks to a highly refined technical design.
• Compact engine for improved handling and overall balance of the bike.

Optimized cooling system Fantic Caballero 500

Water radiator (H2O)

• Increased heat exchange surface for more efficient cooling.
• Increased thermal efficiency by 15% compared to the previous version.

Oil cooler

• Up to 10% reduction in oil temperature.
• Increased thermal stability under demanding driving or in hot climates.

Intake and exhaust optimization Fantic Caballero 500

Intake (Airbox and ducts)

• Volume and geometry optimized through 3D CFD simulations.
• Improved airflow to throttle body and reduced turbulence.
• Increased efficiency and direct engine response.

Exhaust

• Redesigned manifold and muffler with one-dimensional analysis.
• Improved torque curve and more refined characteristic sound.

New geometry and ergonomics Fantic Caballero 500

Redesigned chassis

• Modified geometry for greater steering precision and agility in bends.
• Version-specific configurations: Scrambler and Deluxe with 19" rim, Rally with 21" rim.

Advanced ergonomics

• Narrower leg rests for improved standing support.
• Footpegs 20 mm further inboard for improved stand-up riding, especially off-road.

Functional comfort

• New seat with quick release and document compartment.
• Redesigned passenger handgrips for comfort and safety.
